Small palm oil press machine photo
Small palm oil press machine includes single screw palm oil press machine and double screw palm oil press machine. Both are used to extract crude palm oil from palm fruit. We are using a special process that improves the oil extraction rate, reduces the residual oil rate and insures the integrity of the palm kernel.
Single screw palm oil press machine
The processing capacity of the single screw palm oil press machine is 300-500kg/h. Its working principle is that the squeeze screw in the front and the reducer in the back work at the same time to produce extrusion, so as to achieve the best extrusion effect. In order to improve the applicability of the small single screw palm oil press machine, we have two different power systems of diesel engine and electric motor, the diesel engine power is 8HP and the motor power 4kw, which can be selected to different power conditions.
Single screw palm oil press machine photo
The single screw palm oil press machine can be used alone, or equipped with a simple palm oil press production line according to your own needs. Like a simple palm oil press line equipped with simple type thresher, single screw palm oil press machine and plate filter. Thereby improving the oil yield of palm fruit.
Double screw palm oil press machine
The double screw palm oil press machine uses a 7.5kw motor power system, and its processing capacity is 1-2t/h. The working principle of double screw palm oil press machine is not exactly the same as that of a single screw palm oil press machine. Its tail is equipped with a gearbox, combined with a hydraulic pump station to drive two squeezing screws to rotate relative to each other, and the blades are engaged to discharge oil. The closer to the outlet, the smaller the gap between the blades and the greater the pressure, making the residual oil rate lower and more efficient. It is beneficial to the smoothness of palm fruit pressing.
Double screw palm oil press machine photo
The double screw palm oil press machine is the same as the single screw palm oil press machine. which can be used alone or equipped with a palm oil press production line according to your needs. But the difference is that the double screw palm oil press machine can be equipped with small and medium-sized production lines of 1-5tph, and can be equipped with large palm oil production lines. Taking the production process of a small and medium palm oil production lines as an example, the small and medium palm production line includes sterilizers, threshers, digesters, presses, clarifiers, filters, etc. Its processing capacity can reach 10-120tph. The operation is simple, it is not easy to block the material, and the residual oil rate is lower.
| Capacity | Main Power | Shaft Speed | Weight | Size(mm) | |
Small single screw palm oil press machine | 500 kg/h | Diesel engine: 8HP Motor power: 4kw | 25-35 r/min | 260 kg | 1500*800*200 mm |
Small double screw palm oil press machine | 1, 5, 10, 15 t/h | 7.5-30 kw | 20-12.5 r/min | 180-6500 kg | 3-10 m³ |
Our screws are made of 2Cr13 material, wear-resistant alloy steel and integrated casting process. Normal maintenance can be used for half a year or a year. It can reduce the manpower, material resources and time cost.
Henan Glory Oil & Fats Engineering CO., LTD will customize products according to your needs. If you need small palm oil press equipment, please feel free to contact us.
